What a histogram is
A histogram is a bar chart that shows how often measurements fall into each range (class). It reveals the center, the spread and the shape of a process distribution, which a list of numbers or an average cannot show.
It is one of the 7 basic quality tools. Unlike a Pareto chart, which ranks categories, a histogram works with continuous data (diameter, weight, time, torque) and keeps the bars in the natural order of the values.
Histogram visual map
The map summarizes the step-by-step method, the frequency table of the example and the typical distribution shapes.
How to build one: 6 steps
- Collect at least 50 measurements from the same process, period and gauge. Below 30 points the shape is misleading.
- Compute the range: R = largest value − smallest value.
- Choose the number of classes (k). Sturges' rule gives k = 1 + 3.322 × log10(n). A practical alternative is k ≈ √n.
- Compute the class width: h = R ÷ k, rounded to a convenient value at the gauge resolution.
- Set the class boundaries without overlap (use half a unit more precision than the measurement so no value lands on a boundary) and count each class.
- Draw adjacent bars with frequency on the vertical axis, and mark the mean and the specification limits.
k = 1 + 3.322 × log10(n) | h = R ÷ k
Worked example: shaft diameter
Illustrative example: 50 machined shafts measured in mm, specification 10.00 ± 0.10 mm (LSL = 9.90; USL = 10.10). The smallest value is 9.95 and the largest is 10.06.
- Range: R = 10.06 − 9.95 = 0.11 mm
- Sturges: k = 1 + 3.322 × log10(50) = 1 + 3.322 × 1.699 ≈ 6.64, so 6 to 7 classes
- Width: h = 0.11 ÷ 7 = 0.0157, rounded to 0.02 mm, which gives 6 classes
- First boundary: 9.945, half a unit below the smallest value to avoid ties
| Class (mm) | Frequency | % of total | Cumulative |
|---|---|---|---|
| 9.945 to 9.965 | 3 | 6.0% | 3 |
| 9.965 to 9.985 | 6 | 12.0% | 9 |
| 9.985 to 10.005 | 14 | 28.0% | 23 |
| 10.005 to 10.025 | 17 | 34.0% | 40 |
| 10.025 to 10.045 | 8 | 16.0% | 48 |
| 10.045 to 10.065 | 2 | 4.0% | 50 |
The frequencies add up to 50. The peak is in the 10.005 to 10.025 class (17 parts, 34%) and the distribution is symmetric and bell-shaped. The sample mean is 10.006 mm and the sample standard deviation is 0.0235 mm.
How to read the shape
| Shape | What it indicates | Likely action |
|---|---|---|
| Symmetric bell | Stable process, common causes only | Compare with the specification |
| Skewed | Natural limit on one side (e.g. times, burrs) | Check for a physical or process limit |
| Two peaks (bimodal) | Mix of two sources: two machines, shifts, lots | Stratify the data by source |
| Plateau (flat) | Several means mixed or drift | Investigate wear and setup |
| Truncated (sharp cut) | Nonconforming parts removed before measuring | Measure before sorting |
| Isolated island | Measurement error, wrong entry or rare event | Check the data and the cause |
After the shape, compare with the specification. In the example the smallest value (9.95) is 0.05 mm from the LSL and the largest (10.06) is 0.04 mm from the USL: the tails still fit, but with little margin. If a tail crossed 9.90 or 10.10, there would be nonconforming parts.
From histogram to capability
With a mean of 10.006 and s = 0.0235, potential capability is Cp = (10.10 − 9.90) ÷ (6 × 0.0235) = 0.20 ÷ 0.141 ≈ 1.42. The index that accounts for off-centering is Cpk = min[(10.10 − 10.006); (10.006 − 9.90)] ÷ (3 × 0.0235) = 0.094 ÷ 0.0705 ≈ 1.33. Details and acceptance criteria are in Cp and Cpk.
Cp = (USL − LSL) ÷ 6s | Cpk = min(USL − x̄; x̄ − LSL) ÷ 3s
These indices are only valid if the process is in control. A histogram does not show time order: use a control chart, which detects drift that the histogram hides.
When to use a histogram
- Capability studies: check whether the distribution fits inside the specification limits.
- Variation diagnosis: separate sources when two peaks appear.
- Measurement system checks: data with very few distinct values point to poor gauge resolution, a topic of MSA and Gauge R&R.
- Root cause work with continuous data: look at the shape first, then use an Ishikawa diagram to list causes.
Common mistakes
- Too little data: with 15 or 20 points almost any shape looks possible.
- Too many or too few classes: many classes make the chart ragged; few hide the shape.
- Unequal class widths without adjusting bar height distort the reading.
- Mixing machines, shifts or lots in one sample and concluding the process is bimodal or "wide".
- Confusing it with a bar chart: in a histogram the bars touch and the order is fixed.
- Ignoring time: a nice histogram can come from an unstable process.
Frequently asked questions
How many classes should a histogram have?
Use Sturges, k = 1 + 3.322 × log10(n), or the square root of n. For 50 data points, 6 or 7 classes.
How much data do I need?
The practical minimum is 50 measurements; with 100 the shape is more reliable. Below 30, avoid conclusions.
What is the difference between a histogram and a bar chart?
A histogram shows the distribution of a continuous variable in ordered classes with touching bars. A bar chart compares categories.
How do I calculate the class width?
Divide the range by the number of classes and round. In the example, 0.11 ÷ 7 = 0.0157, rounded to 0.02 mm.
What does a histogram with two peaks mean?
Two populations are mixed, such as two machines or two shifts. Split the data by source and redraw the chart.
Does a histogram replace a control chart?
No. It shows the distribution but not the time order. Use both: the chart for stability, the histogram for shape and capability.
Sources
- MONTGOMERY, D. C. Introduction to Statistical Quality Control. Wiley.
- ISHIKAWA, K. Guide to Quality Control. Asian Productivity Organization.
- AIAG. Statistical Process Control (SPC) Reference Manual. 2nd ed.
- WHEELER, D. J. Understanding Variation: The Key to Managing Chaos. SPC Press.
